Lab Facilities

Lab Facilities

A fully equipped lab with electronics and mechanical prototyping capabilities

Electronics instrumentation

  • Sigilent¬†SDS5104X 1GHz, 5GSa/s mixed signal scope
  • Sigilent SDG6052X 500MHz pulse / arbitrary waveform generator
  • ¬†Sigilent SSA3032X 9KHz to 3.2GHz spectrum analyzer
  • 16 channel 500MHz Logic analyzer
  • Bluetooth analyzer
  • USB analyzer
  • SPI, RS232, I2C analyzer
  • 8MHz differential probes
  • Current probes
  • Programmable bench top three channel DC power supply
  • Programmable 50A load control box
  • Precision 7.5 digit multi meter
  • Temperature and FLIR instruments

Electronics prototyping

  • Weller soldering de-soldering stations
  • Stencil printer
  • Pick & place machine
  • Manual pick & place station
  • Reflow oven

Mechanical prototyping

  • Lulzbot 3D printer
  • Carbide CNC machine
  • Sheet metal brake & other tools
  • Drill press
  • Low volume plastic injection molding machine
  • Aluminum mold making tools
