Embedded systems and mechatronics design

Design Services

Systems level approach to product design
Product Design

Electronics design

Firmware & Software development

Mechanical Design & Prototyping

Project Portfolio

A selection of recently completed projects
Cryogenic device controller
Cryogenic device controller
Motor control, LTE modem, RFID, color display, thermistors, valve driver, fan speed control
A full mechatronics system in a miniaturized package consisting of a stepper driver, multiple temperature sensors, fans, valves, TFT touch display, RFID for consumable tracking and a cellular LTE module for connection to a cloud server for device maintenance and updates. Project included electronics board development, firmware (C for PIC24) and a GUI (visual studio C#).
Smart Thermostat
Smart Thermostat
E-ink display, LoRA, Bluetooth LE, WiFi
Electronics, firmware and enclosure design for a production ready smart thermostat consisting of a HVAC control loop with LoRA , WiFi and Bluetooth LowEnergy with a Microchip PIC24 microcontroller
Multi-Axis Brushless motor controller
Multi-Axis Brushless motor controller
4-axis BLDC controller with Rs485 and valve drivers
Compact 4A per axis, 24V BLDC controller based on Performance Motion Devices MC58420 chipset
Scintillation detector
Scintillation detector
1.4GHz ADC, FPGA, 16-bit Microcontroller for photomultiplier pulse detection
A novel radio isotope detector using multiple photomultiplier tubes, unique low noise high speed analog front end design, High speed ADC(2Gsps), Xilinx FPGA, microcontroller, motor control, display and usb communications for use with HPLC, UPLC and other high resolution liquid chromatography equipment
Bluetooth LE data loggers
Bluetooth LE data loggers
Blouetooth low energy 5.0 multi sensor data loggers
A bluetooth low energy based data logger with optional RS232 link. Designed to interface to thermistors, pressure sensors or any SPI, RS232, I2C sensors.
Linux base station
Linux base station
ATSAM9x25 muti interface base station for smart grid application development
ATSAM9x25 based linux base station with multiple network interfaces – Ethernet, WiFi, CAN, RS232, HomePlug, Zigbee, USNAP, Bluetooth LE – for smart grid applications
Brushless motor speed controller
Brushless motor speed controller
360VDC BLDC speed controller with CAN interface
A XC164 based high voltage (360VDC) fuel pump (brushless dc) controller. Used in a battery cooling application of an electric vehicle.
Milli-watt energy harvestor
Milli-watt energy harvestor
Multi input milli-watt energy harvester and LiFePo4 charger
A unique design that harvest energy from multiple sources – solar, wind, thermal, tidal – and uses a MPPT based algorithm to charge a LiFePo4 battery.

Products

Product lines developed by Automation Research Group
Power Line Systems
Power Line Systems
IOT over power lines
City or building wide private air gapped networks on power lines for data and control without any new wires or wireless infrastructure.
ARGUS Sensors
ARGUS Sensors
Bluetooth LE mesh sensors
Bluetooth low energy mesh based sensors for building automation

Clients

A selected list of clients that we have worked with:

Contact us for a free design consulation

Products

Product lines developed by Automation Research Group
Power Line Systems
Power Line Systems
IOT over power lines
City or building wide private air gapped networks on power lines for data and control without any new wires or wireless infrastructure.
ARGUS Sensors
ARGUS Sensors
Bluetooth LE mesh sensors
Bluetooth low energy mesh based sensors for building automation
